YX-FG0350
Information
Building Louvres —— Facade
| Infill blade | Aluminum blade |
| Blades span | Max. 4000 mm |
| Blade angle | 35-70° |
| Blade direction | Horizontal or Vertical |
| Louver blade | Fixed |
Product Parametes
| Optiona blade | Optional size | Blade direction | Blades span | Frame size | ||
 |
Rectangular blade | 25*75 | Horizontal / Vertical | 3000 | 50*100 | |
| Rectangular blade | 20*100 | Horizontal / Vertical | 3000 | 50*100 | ||
| Rectangular blade | 50*100 | Horizontal / Vertical | 3500 | 50*100 | 50*150 | |
| Rectangular blade | 50*150 | Horizontal / Vertical | 4000 | 50*150 | ||
| Rectangular blade | 50*200 | Horizontal / Vertical | 4000 | 50*150 | ||
| Rectangular blade | 50*250 | Horizontal / Vertical | 4000 | 50*150 | ||
| Rectangular blade | 50*300 | Horizontal / Vertical | 4000 | 50*150 | ||
 |
Airfoil blade | 23*100 | Horizontal / Vertical | 3500 | 50*100 | |
| Airfoil blade | 30*120 | Horizontal / Vertical | 4000 | 50*100 | ||
| Airfoil blade | 30*150 | Horizontal / Vertical | 4000 | 50*100 | 50*150 |
|
FOSHAN NANHAI YUEXING HARDWARE PRODUCTS.,LTD
Founded in 1992, Yuexing Hardware specializes in architectural hardware.
1.Main Products:Stair handrails, balcony fences, bathroom glass clamps and curtain wall hardware accessories.
2.Strengths:Reliable, cost-effective hardware solutions backed by a mature local supply chain.
